Nabertherm Top 100 Kiln with AC590 Controller

***Please allow 3-4 weeks for delivery***Pre Order**

Nabertherm Top 100 Kiln with AC590   Controller

The attractive design, low weight, and unbeatable price-performance ratio are just a few of the advantages of our top loaders. These models always deliver perfect firing results and are the right choice for hobby potters and workshops.

The particularly energy-saving refractory insulation and energy efficient backing insulation ensure that a maximum temperature of 1320 °C is reached with low electrical connected loads.

These top loaders are ideal for working temperatures between 900 °C and 1230 °C. For intensive professional use, we recommend our rectangular top loaders or chamber kilns with heating from five sides.

Standard design:

• Heating elements protected in grooves, heating from all around
• Two-layer refractory insulation and energy saving backing insulation
• Thermocouple protected in the kiln wall
• Sturdy, locking castors for easy movement of the kiln
• Defined application within the constraints of the operating instructions

Internal Dimentions 480mm Diameter  x 570mm Height

Volume 100 L

Outer Dimentions  660mm W x 970mm D x 1000mm H

7KW  30AMP Supply - Single Phase

102KG Weight

Supplied with:

• The simple and versatile AC590 Controller
• Base frame with castors (castors not attached on delivery, but are easy to put on).

Program Controller AC590:

Features:

• Touch Screen
• Wi-Fi Capable
• MyNabertherm App
• Easy and individual programming
• 50 programs can be stored
• Delayed start time of the kiln (e.g. for using economy 7)
• 40 freely adjustable segments
• Input of the set points in increments of 1°C and/or 1min.
• Skip-button to bypass a segment while the program is running
• Hold times may be extended while the program is running

Controller

The AC590 controller, which is included in the price of the kiln, has 50 customisable programs each with 40 segments. So now only one controller for the Nabertherm's 'arts and crafts' kilns.

There is also a new feature called 'conny', a cone firing assistant, 'solar mode' for using the kiln with photovoltaic systems and not forgetting Nabertherm's app allowing remote viewing.

STANDARD EQUIPMENT
